Electronics-Salon RJ45 8P8C 9-Way Buss Board DIN Rail Mount Interface Module.
Product Code: HSM24218
Availability: Pre-Order, Inquiry Price
Availability: Pre-Order, Inquiry Price
Description
RJ45 9-Way Buss Board DIN Rail Mount Interface Module.
Part number: MD-D238T.
RJ45 vertical shielded 8P8C jacks.
DIN rail mountable - for width 35 / 32 / 15mm rails.
DIN mount case can be taken apart for panel mount use.
High quality PCB housing/carrier.
FR-4 fiber glass PCB, dual copper layers.
External dimensions: 72.5 x 83 x 42mm(W x L x H).
PCB dimensions: 72.5 x 80(W x L).
100% new, never used.
Rated voltage: 100V.
Rated current: 500mA / per pin.
Operating Temperature: -20ºC to 50ºC
?
