Electronics-Salon Arduino Screw Terminal Block Breakout Module, for Arduino UNO R3.

Electronics-Salon Arduino Screw Terminal Block Breakout Module, for Arduino UNO R3.

Product Code: HSM23742
Availability: Pre-Order, Inquiry Price

US$11.39

- +

For Bulk Order, Get Better Price.

About this product

*Terminal Block Breakout Module - for Arduino UNO R3. the item has been soldered and assembled.

*Terminal block pitch 3.5mm/0.138", wire size range 26AWG to 16AWG, strip length 5mm, screw M2 steel, pin header and cage copper.

*Standard IDC40 pitch 0.1" header, you can use 40pin FRC(flat ribbon cable) connector cable connect all Arduino Uno pins to peripheral equipment.

*With power on LED indicating. red reset button on the side. with a ICSP adapter connect header. FR-4 fiber glass PCB, dual copper layers.

*NOTE: the item not include Arduino Uno module

Description

Terminal Block Breakout Module - for Arduino UNO R3. the item has been soldered and assembled.
Terminal block pitch 3.5mm/0.138", wire size range 26AWG to 16AWG, strip length 5mm, screw M2 steel, pin header and cage copper.
Standard IDC40 pitch 0.1" header, you can use 40pin FRC(flat ribbon cable) connector cable connect all Arduino Uno pins to peripheral equipment.
With power on LED indicating. red reset button on the side. with a ICSP adapter connect header. FR-4 fiber glass PCB, dual copper layers.
NOTE: the item not include Arduino Uno module
