100A Waterproof Marine Thermal Circuit Breaker with Manual Reset, 12V- 48VDC
Availability: In Stock
About this product
*◆ Meet S.A.E. J1625, J1171, UL1500 (Ignition Protected)
*◇ Material: Bakelite material has high mechanical strength, can run well in the range of DC 42V and current 50~300A, and has good heat resistance and corrosion resistance.
*◆ Performance: IP67 waterproof grade, insulation material design, high sensitivity, high and low temperature resistance from -32℃ to 82℃ (-25℉ to 180℉), can protect the circuit in time.
*◇ Manual reset switch: When the circuit is broken, it will be automatically disconnected by pressing it once; when the circuit returns to normal, push the disconnected handle back to continue monitoring the circuit.
*◆ Embedded installation: Drill holes according to the size of the circuit breaker, then connect the circuit breaker BAT to the positive pole and AUX to the negative pole.
Description
-Manual Reset Circuit BreakerÂ
-Power Rating: 100 AmpÂ
-Voltage: Up to 42V DC
-Manual Reset ButtonÂ
-Splash and Dust Proof at IP67 gradeÂ
-Temperature: -32? to 82? (-25? to 180?)
-Terminals: 1/4" Stainless Steel Studs
-Embedded installation, protective stud insulator included
-Regulatory Sepcification: S.A.E, J1625, J1171, UL1500
Features:Â
-Water resistant housing.Â
-High Current Circuit Breaker, to protect to your system.Â
-Self-test, manual control and easy to operate with manual reset arm.Â
-Prevents excessive current and stops power surges from damaging Amps.Â
-Can be mounted on Panel or Firewall.Â
-Unique Push Button Reset can also be used as a Kill Switch.Â
-Typically used in truck, bus, RV and marine applications; also used in battery charges and DC sound system.Â
Packing:
1 * 100 Amp Circuit Breaker with Manual Reset
Note:
Please install it according to the size of the circuit breaker. Professional installation is recommended.
