CHANCS TYD-50 Synchronous AC Motor 110V 5-6RPM CW/CCW Small Electric Gear Motor for Electric Fireplace
Availability: In Stock
About this product
*This is a TYD-50 AC 110V 5-6RPM CW/CCW synchronous motor,small power consumption, low noise, small size, light weight, easy to use. The reduction gear is combination of metal/plastic to ensure the gear working continuously and quietly. We promise we will tested ever motor before shipment.
*【Specification:】 Product Name : Synchronous Motor； Model : TYD-50； Shaft Diameter: 7mm ； Shaft Length: 11mm； Shaft Hole Screw Thread: M4 (φ3.4mm /0.13")； Direction : CW/CCW(UNCONTROLLABLE)； Voltage : AC 110V-130V； Speed : 5-6RPM/min； Power : 4W； Torque:≤4.8kg*cm； Frequency : 50/ 60Hz；
*【Application:】 Suitable for Barbecue Rotisserie , Party BBQ. Widely used in hand-made, school project, electric fan shake heads, heaters, Christmas tree, prayer cylinders, air conditioners, microwave ovens, glue machines, electric ovens, rotating lamps, electric tables, electric models, electric advertising, electric shelves, dishwashers, control appliances , curtain machines, etc.
*【Package Content:】1 x Synchronous Motor
*【Attention:】 1.The applicable voltage of this motor is AC 110V-130V, too high voltage will burn the motor. 2.The motor speed is not an accurate value, the speed will change with the frequency. For example, the speed is 0.8-1RPM, at 50 Hz, the speed is 0.8RPM; at 60 Hz, the speed is 1RPM.
Description
This is a TYD-50 AC 110V-130V 5-6RPM synchronous motor,small power consumption,
low noise, small size, light weight, easy to use. The reduction gear is combination of metal/plastic to ensure the gear working continuously and quietly.
We promise we will tested ever motor before shipment.
?Specification:?
Product Name : Synchronous Motor
Model : TYD-50
Shaft Diameter: 7mm
Shaft Length: 11mm
Direction : CW/CCW(UNCONTROLLABLE)
Voltage : AC 110V-130V
Speed : 5-6RPM/min
Power : 4W
Torque:?4.8kg*cm.
Frequency : 50/ 60Hz
?Application:?
Widely used in hand-made, school project, electric fan shake heads, heaters,
Christmas tree, prayer cylinders, air conditioners, microwave ovens, glue machines, electric ovens, rotating lamps,
electric tables, electric models, electric advertising, electric shelves, dishwashers, control appliances , curtain machines, etc.
?Package Content:?
1 x Synchronous Motor
?Attention:?
1.The applicable voltage of this motor is AC 110V-130V, too high voltage will burn the motor.
2.The motor speed is not an accurate value, the speed will change with the frequency. For example, the speed is 0.8-1RPM,
at 50 Hz, the speed is 0.8RPM; at 60 Hz, the speed is 1RPM.
