Taramps BASS 5K 1 Ohm 5000 Watts Class D Mono Amplifier

Taramp's BASS line of amplifiers is built exclusively for high performance on bass speakers, providing precise adjustments for optimal power and sound quality.

Technical Specs:

Operation Class: DNumber Of Channels: 01Maximum Power:@ 14.4 Vdc - 1 Ohm: 5000 W Rms@ 14.4 Vdc - 2 Ohms: 3200 W RmsInput Sensitivity: 220mVSignal to Noise Ratio:> 95DbFrequency Response: 8Hz to 250Hz (-3Db)Crossover High Pass (Hpf): Variable, 8 to 30Hz (-12Db / 8th)Crossover Low Pass (Lpf): Variable, 60 to 250Hz (-12Db / 8th)Bass Boost: Parametric, 35 - 60Hz, 0 ~ + 10DbEfficiency: 83%Input Impedance: 22K OhmsOutput Impedance: 1 OhmProtection System: Short On Output, Short On Output Regarding Gnd, Low Impedance Protection, High / Low Voltage Protection And Thermal Protection.Min. Supply Voltage: 9 VdcMaximum Power Rating: 17 VdcConsumption At Rest: 1.20 AmpMusical Maximum Consumption: 209 AmpMaximum Consumption in Sinusoidal Signal: 418 AmpDimensions (WxDxH): 239 X 73 X 327 mmWeight: 5 kg
