Dayton 1TDN5 Blower, 53 CFM, 115V, 0.30 Amp, 3388 RPM

OEM Blower, Outlet Shape Rectangular, With/Without Flange With Flange, Wheel Dia. 2-15/16", Wheel Width 1-7/8", CFM @ 0.000-In. SP 53, CFM @ 0.100-In. SP 52, CFM @ 0.200-In. SP 50, CFM @ 0.300-In. SP 47, CFM @ 0.400-In. SP 41, CFM @ 0.500-In. SP 23, Voltage 115, Hz 50/60, Phase 1, Full Load Amps 0.30, RPM 3388, Bearing Type Ball, Motor Type Permanent Split Capacitor, Motor Enclosure Open, Motor Insulation Class B, Thermal Protection Auto, Lead Length 13", Conduit Box No, Max. Ambient Temp. 104 Degrees F, Max. Inlet Temp. 104 Degrees F, Inlet Dia. 2-9/16", Outlet Height 1-5/8", Outlet Width 2", Overall Height 4-5/8", Overall Width 4-11/16", Overall Depth 4-1/2", Wheel Type Forward Curve, Drive Type Direct, Mounting Position All Position, Housing Finish Enamel, Housing Material Rolled Steel, Housing Color Gray, Agency Compliance UL Recognized US and Canada (E47479), CE, Replaces 4C012, Includes Discharge Mounting Flange.
